HP 11 Maintenance And Service Guide

System board
NOTE: The system board spare part kit includes replacement thermal material.
Description Spare part number
HP Pavilion TouchSmart 11 Notebook PC/ HP Pavilion 11 Notebook PC
Equipped with an AMD A4-1250 processor, a graphics subsystem with UMA memory, for use on
computers with Windows 8.1 Standard operating system
744789-501
Equipped with an AMD A6-1450 processor, a graphics subsystem with UMA memory, for use on
computers with the Windows 8.1 Standard operating system
744790-501
HP 215 G1 Notebook PC
Equipped with an AMD A4-1250 processor, a graphics subsystem with UMA memory, for use on
computers with Windows 7 operating system
744185-001
Equipped with an AMD A4-1250 processor, a graphics subsystem with UMA memory, for use on
computers with Windows 8.1 Standard operating system
744185-501
Equipped with an AMD A4-1250 processor, a graphics subsystem with UMA memory, for use on
computers with Windows 8.1 Professional operating system
744185-601
Equipped with an AMD A6-1450 processor, a graphics subsystem with UMA memory, for use on
computers with Windows 7 operating system
744189-001
Equipped with an AMD A6-1450 processor, a graphics subsystem with UMA memory, for use on
computers with Windows 8.1 Standard operating system
744189-501
Equipped with an AMD A6-1450 processor, a graphics subsystem with UMA memory, for use on
computers with Windows 8.1 Professional operating system
744189-601
Before removing the system board, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 33), and then remove the following components:
a. Service door (see
Service door on page 34)
b. Hard drive (see
Hard drive on page 35)
c. Display assembly (see
Display assembly on page 46)
d. Bottom cover (see
Bottom cover on page 54)
e. Media card reader board (see
Media card reader board on page 60)
f. Fan (see
Fan on page 61)
Component replacement procedures 63
