Hard Drive
Description Spare part number
1-TB 621418-001
750-GB 632938-001
500-GB 621421-001
320-GB 621420-001
250-GB 621419-001
The hard drive is located on the left side of the computer (viewed from behind). The drive is secured
with one captive screw and is housed in a removable cage.
1. Prepare the computer for disassembly (see Preparing to Disassemble the Computer
on page 37).
2. Remove the rear cover (see
Rear Cover on page 38).
3. Loosen the captive Phillips screw that secures the drive to the computer (1).
Hard Drive 59
