Display assembly

Description Spare part number

Display bezel

For use in black models 929635-001

For use in white models 929636-001

For use in blue models L00444-001

Display cable (includes display panel cable and camera/microphone cable) 929637-001

Camera/microphone module

HD camera 919471-002

VGA camera 919472-002

Antenna, dual (includes wireless antenna cable and transceiver) 929632-001

Raw display panel (35.6-cm [14.0-in])

UWVA, Brightview 847660-008

UWVA, anti glare 821816-005

SVA, Brightview 847664-008

SVA, anti glare 916357-004

Hinge Kit (left and right) 929640-001

Display enclosure:(does not include wireless antennas)

For use in black models 929633-001

For use in white models 929634-001

For use in blue models L00445-001

This section describes removing the display assembly and disassembling display subcomponents. You must

remove the display from the computer to disassemble display subcomponents.

Before removing the display assembly, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then

unplugging the AC adapter from the computer.

4. Remove the bottom cover (see Bottom cover on page 32).

5. Remove the battery (see Battery on page 34).

6. Remove the fan assembly (see Fan on page 42).

To remove the display assembly:

1. Disconnect the display panel cable from the system board (1).

2. Disconnect the wireless antennas from the WLAN module (2).

56 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts
