Special displays
Interleaved Trace Lists
Interleaved trace lists allow you to view data captured by two or more
analyzers in a single trace list. When you interleave the traces, you see
each state that was captured by each analyzer. These states are
shown on consecutive lines.
You can interleave state listings from HP 16510B, 16540A, 16540D,
and 16550A state analyzers, when two or more are used together in a
group run. Interleaved state listings are useful when you are using
multiple analyzers to look at interaction between two or more
processors. They are also useful when you need more analysis width
than is available in one analyzer.
Mixed Display Mode
The Mixed Display mode allows you to show state listings and
waveforms together on screen, if all were obtained by modules within
the HP 16500C and 16501A frame. State listings are shown at the top
of the screen and waveform displays are shown at the bottom. You can
interleave state listings from two analyzers at the top of the screen, if
desired. You can display waveforms from two oscilloscopes or timing
analyzers at the bottom of the screen.
2–21
