Making Connections
Connecting External Components
66 User's Guide
Connecting External Components
External components such as a printer, mouse, monitor, or keyboard may be connected
directly to your computer. However, if you have purchased the optional port replicator,
you can use it to connect external components without disconnecting them each time you
wish to use the computer on the road.
To identify the ports
Using the ports on the rear of the computer or on the port replicator, the following
external components are readily connected. Table numbers refer to a callout number on
the figures.
Port location on
Component Pavilion Port replicator
Printer (parallel) 1 11
Printer (infrared) 6 --
Printer (serial) 2 10
Monitor 3 12
PS/2 mouse 8* 13
PS/2 keyboard 8* 13
USB device 7 14
Infrared device 6 --
Speakers 4 16
Microphone 5 17
Audio-in -- 15
* You can use a Y adapter (HP F1469A) to connect both a keyboard and mouse to your
Pavilion.
