Display assembly
This section describes removing the display assembly and disassembling display subcomponents.
If you only need to remove the display bezel, webcam/microphone module, or display panel, you do not need
to remove the entire display assembly from the computer.
Description Spare part number
Raw display panel (35.6-cm [14.0-in], HD, WLED, BrightView; includes insulator screws)
For use in HP Notebook models without a touch screen 813518-001
For use in HP Notebook models with a touch screen 813520-001
For use in HP 240/246 G4 models 814811-001
Antenna (includes insulator screws)
Single antenna 813485-001
Dual antennas (HP 240/246 models only) 813486-001
Display bezel (includes insulator screws)
For use in HP Notebook models 813501-001
For use in HP 240 G4 Notebook models 814810-001
For use in HP 246 G4 Notebook models 815845-001
Display cable (includes display panel cable and webcam/microphone cable; includes insulator screws)
For use in non-touch screen models 813503-001
For use in touch screen models 814042-001
Display enclosure for use in HP Notebook models (includes insulator screws)
Black models 813497-001
Red models 813493-001
White silver models 813487-001
Turbo silver models 813495-001
Blue models 813489-001
Purple models 813491-001
Display enclosure for use in HP 240/246 G4 Notebook models (includes insulator screws) 814808-001
Hinges (left and right) (includes insulator screws) 813511-001
Webcam/microphone module (includes insulator screws)
VGA 813525-001
HD 813527-001
Before removing the display assembly, follow these steps:
Component replacement procedures 61
