HP 2509p User Manual

Technical Specifications
User’s Guide B–3
Preset Video and High-Definition Modes
The monitor automatically recognizes many preset video input modes that will appear properly sized and centered
on the screen.
Factory Preset Video Input Modes, 2309p and 2509p
Preset Resolution
Horizontal
Frequency (kHz)
Vertical
Frequency (Hz)
1 640 x 480 31.47 59.94
2 720 x 400 31.47 70.09
3 800 x 600 37.88 60.32
4 1024 x 768 48.36 60.00
5 1280 x 720 45.00 60.00
6 1280 x 960 60.00 60.00
7 1280 x 1024 63.98 60.02
8 1440 x 900 55.94 59.89
9 1600 x 1200 75.00 60.00
10 1680 x 1050 65.29 60.00
11 1920 x1080 67.50 60.00
High Definition Video Formats
Preset Timing Name Resolution
Horizontal
Frequency (kHz)
Vertical
Frequency (Hz)
1 480p60 720 x 480 31.47 60
2 720p60 1280 x 720 45.00 60
3 576p50 720 x 576 31.25 50
4 720p50 1280 x 720 37.50 50
5 1080p60 1920 x 1080 67.50 60
6 1080p50 1920 x 1080 56.25 50

HP 2509p Specifications

General

Brand	HP
Model	2509p
Category	Monitor
Language	English
