Operating Information
Model 8756A
3-14
SOFT KEY OPERATING FEATURES
MAIN MENU
(_hp"J f~l ~ ~B/ REF + 00 dB
REF I
I
\
!/
1\
I \
1/
1\
v
\
STRT +2. 0000GH:z: STOP +6 • 00B0GHz
AVERAGE
CA~
PLOT
LABEL~
ON/OFF1
MORE
The MAIN MENU is the primary means of selecting all of the Soft
Key functions and menus. When the MAIN MENU or PRESET key is
pressed, the MAIN MENU of Soft Keys is always displayed. A
particular soft key menu or function is selected by then
pressing the key to the immediate right of the label on the CRT
display. Selection of MAIN MENU does not alter any previously
selected function parameter, either from the Front Panel or
Soft Key. The following pages describe each Soft Key menu or
function listed in the MAIN MENU.
Figure 3-2. Soft Key Operating Features (1 of 10)
