TouchPad board and TouchPad button board

NOTE: The top cover, spare part number 500002-001, includes the TouchPad board and cable, and

the TouchPad button board and cable.

Before removing the TouchPad board and TouchPad button board, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

then unplugging the AC adapter from the computer.

4. Remove the battery (see

Battery on page 37).

5. Remove the following components:

a. Hard drive (see

Hard drive on page 38)

b. Optical drive (see

Optical drive on page 45)

c. Keyboard (see

Switch cover and keyboard on page 47)

d. Switch cover (see

Switch cover and keyboard on page 47)

e. Speaker (see

Speaker on page 51)

f. Display lid switch module (see

Display lid switch module on page 52)

g. Display assembly (see

Display assembly on page 53)

h. Top cover (see

Top cover on page 58)

Remove the TouchPad board and TouchPad button board:

1. Turn the top cover upside down, with the front toward you.

2. Release the ZIF connectors on the TouchPad button board (1) and TouchPad board (2) to which

the TouchPad board cable is connected.

3. Disconnect and remove the TouchPad board cable (3).

Component replacement procedures 61
