Right side
Item Component Description
(1) Optical drive Reads and writes to an optical disc.
(2) Optical drive light
{
On: The optical drive is in use.
{
Off: The optical drive is idle.
(3) USB ports (2) Connect optional USB devices.
(4) Power connector Connects an AC adapter.
(5) AC adapter light
{
White: The computer is connected to external power
and the battery is fully charged.
{
Amber: A battery is charging.
(6) Security cable slot Attaches an optional security cable to the computer.
NOTE: The security cable is designed to act as a
deterrent, but it may not prevent the computer from being
mishandled or stolen.
Right side
15
