Item Component Spare part number
Screws (not illustrated)
(3) Optical drive (select models only; includes bezel and bracket):
Blu-ray Disc ROM with SuperMulti DVD±R/RW Double-Layer Drive with LightScribe 646127-001
DVD±RW and CD-RW Super Multi Double-Layer Combo Drive with LightScribe 646126-001
Plastics Kit
Item Component Spare part number
Plastics Kit, includes: 646131-001
(1) Hard drive compartment cover (includes one captive screw, secured by a C-clip)
(2) Memory module/wireless module compartment cover (includes one captive screw, secured by a C-clip)
28 Chapter 3 Illustrated parts catalog
