3.
Detach the RTC battery (2) from the system board. (The RTC battery is attached to
the system board with double-sided tape.)
4. Remove the RTC battery.
Reverse this procedure to install the RTC battery.
Fan/heat sink assembly
NOTE: The fan/heat sink assembly spare part kit includes replacement thermal material.
Description Spare part number
For use only with computer models equipped with an AMD Athlon II, Phenom II, Turion II, or V-
Series processor and a graphics subsystem with discrete memory
647319-001
For use only with computer models equipped with an AMD Athlon II, Phenom II, Turion II, or V-
Series processor and a graphics subsystem with UMA memory
647318-001
For use only with computer models equipped with an AMD E350 or E240 processor and a graphics
subsystem with discrete memory
647317-001
For use only with computer models equipped with an AMD E350 or E240 processor and a graphics
subsystem with UMA memory
647316-001
For use only with computer models equipped with an Intel Dual Core i5 or i3 processor and a
graphics subsystem with discrete video memory
646182-001
For use only with computer models equipped with an Intel Dual Core i5 or i3 processor and a
graphics subsystem with UMA video memory
646183-001
For use only with computer models equipped with an Intel Pentium processor and a graphics
subsystem with discrete video memory
646180-001
For use only with computer models equipped with an Intel Pentium processor and a graphics
subsystem with UMA video memory
646181-001
For use only with computer models equipped with an Intel Celeron or Core 2 processor and a
graphics subsystem with UMA video memory
646184-001
Component replacement procedures
79
