Before removing the solid-state drive, follow these steps:
1. Shut down the computer.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
4. Remove the following components:
a. Service door (see Service door on page 37).
b. Remove the battery (see Battery on page 38)
c. Hard drive (see Hard drive on page 39).
Remove the solid-state drive:
▲
Remove 1 Phillips M2.0x8 screw (1), and then remove the solid-state drive (2).
Reverse this procedure to install the solid-state drive.
WWAN module (select products only)
NOTE: The WWAN module spare part kit includes the cable.
Description Spare part number
WWAN module
T77W595 LTE M.2 with GPS 800870-002
Huawei Wrangler 2 HSPA+M.2 918670-852
Macan ME906S LTE with GPS M.2 918671-852
42 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts

HP 645 G3 Specifications

General

Operating System	Windows 10 Pro
Processor	AMD PRO A10-8730B
Display	14-inch diagonal HD SVA anti-glare (1366 x 768)
Weight	Starting at 1.9 kg
Battery	3-cell, 48 Wh Li-ion
Ports	HDMI, VGA, Ethernet, headphone/microphone combo jack
Wireless	Bluetooth 4.2
Storage	Up to 512 GB SATA SSD or 1 TB HDD
Graphics	Integrated AMD Radeon R5 Graphics
