Reverse this procedure to install the RTC battery.
Speaker
NOTE: The speaker spare part kit includes the speaker cable.
Description Spare part number
Speaker Kit 840700-001
IMPORTANT: Make special note of each screw and screw lock size and location during removal and
replacement
Before removing the speaker, follow these steps:
1. Shut down the computer.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
4. Remove the following components:
a. Service door (see Service door on page 37).
b. Remove the battery (see Battery on page 38)
c. Hard drive (see Hard drive on page 39).
d. Solid-state drive (see Solid-state drive (select products only) on page 41).
e. WWAN module (see WWAN module (select products only) on page 42).
f. WLAN module (see WLAN module on page 43).
g. Optical drive (see Optical drive on page 45).
h. Keyboard (see Keyboard on page 47).
i. Hinge covers (see Hinge cover on page 53).
j. Base enclosure (see Base enclosure on page 55).
k. System board (see System board on page 57).
l. Fan/heat sink assembly (see Fan and heat sink assembly on page 59).
m. Top cover (see Top cover and TouchPad on page 63).
Remove the speaker:
1. Disconnect the speaker cable (1)...
2. Remove 2 Phillips screws (2).
68 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts
