8-18
Preset State and Memory Allocation
Memory Allocation
Table 8-6 Suffix Character Definitions
Char 1 Definition Char 2 Definition
I, P
Instrument state
a
W Four-channel instrument state
G Graphics 1
0
Display graphics
Graphics index
D Error corrected data 1
2
3
4
Channel 1
Channel 2
Channel 3
Channel 4
R Raw data 1 to 4
5 to 8
Channel 1/3, raw arrays 1 to 4
b
Channel 2/4, raw arrays 5 to 8
F Formatted data 1
2
3
4
Channel 1
Channel 2
Channel 3
Channel 4
C Cal K Cal kit
1 Cal data, channel 1 0
1 to 9
A
B
C
Stimulus state
Coefficients 1 to 9
Coefficient 10
Coefficient 11
Coefficient 12
2 Cal data, channel 2 0 to C same as channel 1
M Memory trace data 1
2
3
4
Channel 1
Channel 2
Channel 3
Channel 4
S
Error corrected data (S2P)
c
1
2
Channel 1
Channel 2
a. These are two-channel instrument states readable by previous firmware versions.
b. Files R1 through R8 will be saved if a full two-port calibration is active. Otherwise, only R1
is saved for Channel 1, R5 for Channel 3, R2 for Channel 2, and R6 for Channel 4.
c. These files are written only when a 2-port error correction (full 2-port or TRL) has been
applied.
