1-46
HP 8719/20/22ES Specifications and Characteristics
Instrument Specifications
Speed Parameters
Table 1-42 HP 8719/20/22ES Measurement and Data Transfer Speed Performance
Typical Time for Completion (ms)
Description
Number of Points
51 201 401 1601
Swept Stepped Swept Stepped Swept Stepped Swept Stepped
Typical Time for Completion (in ms), Start 1 GHz, Span 10 MHz, IFWB=6000
Uncorrected 27 134 65 492 116 970 419 3836
1-port and Enh. Resp. cal
a
a. S11 1-port calibration, with a 6 kHz IF bandwidth. Includes system retrace time, but does
not include bandswitch time. Time domain gating is assumed off.
27 134 65 492 116 970 419 3836
2-port cal
b
b. S21 measurement with full 2-port calibration, using a 6 kHz IF bandwidth. Includes
system retrace time and RF switching time, but does not include bandswitch time. Time
domain gating is assumed off.
80 492 158 1034 259 2010 866 7885
Typical Time for Completion (in ms), Start 50 MHz, Stop 13.5 GHz, IFWB=6000
Uncorrected 484 597 553 1014 614 1490 926 4336
1-port and Enh. Resp. cal
a
484 597 553 1014 614 1490 926 4336
2-port cal
b
996 1222 1133 2069 1259 3057 1876 8892
Typical Time for Completion (in ms), Start 50 MHz, Stop 20 GHz, IFWB=6000
Uncorrected 449 581 538 1017 598 1490 900 4335
1-port and Enh. Resp. cal
a
449 581 538 1017 598 1490 900 4335
2-port cal
b
930 1192 1106 2172 1227 3053 1826 8892
Typical Time for Completion (in ms), Start 50 MHz, Stop 40 GHz, IFWB=6000
Uncorrected 570 731 651 1162 707 1690 961 4519
1-port and Enh. Resp. cal
a
570 731 651 1162 707 1690 961 4519
2-port cal
b
1168 1162 1333 2367 1444 3439 1949 9269
Time Domain
c
(increase over uncorrected sweep time), Gating in Frequency Domain
c. Option 010 only, gating off.
Transform 13 42 87 380
Gating 15 41 81 350
HP-IB Data Transfer
d
:
d. Measured with HP Omnibook 7100 Pentium Pro computer.
Binary (Internal) 11 15 20 54
IEEE floating point format
32 bit 11 18 26 78
64 bit 13 24 40 134
ASCII 33 105 203 781
