1-40
HP 8719/20/22ES Specifications and Characteristics
Instrument Specifications
General Information
Table 1-36 General Information
HP 8719/20/22ES General Information
Description Specification Supplemental Information
Display Range
Magnitude ±200 dB (at 20 dB/div), max
Phase ±180°, max
Polar 10 pico units, min
1000 units, max
Display Resolution
Magnitude 0.001 dB/div, min
Phase 0.01°/div, min
Reference Value Range
Magnitude ±500 dB, max
Phase ±360 °, max
Reference Level Resolution
Magnitude 0.001 dB, min
Phase
0.01°, min
Marker Resolution
Magnitude 0.001 dB, min
Phase
0.01°, min
Polar 0.01 mUnit, min; 0.01, min
