HP 8719/20/22ES Specifications and Characteristics
Instrument Specifications
Table 1-44 Sweep Time vs. IF Bandwidth
IF Bandwidth
Typical Sweep Time (seconds)
a
a. Preset condition, CF = 1 GHz, Span = 100 MHz; includes retrace time, 201 points.
6000 0.066
3700 0.091
3000 0.116
1000 0.243
300 0.700
100 2.018
30 7.058
10 21.475
Table 1-45 Sweep Time vs. Number of Points
Number of Points
Typical Sweep Time (seconds)
a
a. Preset condition, CF = 1 GHz, Span = 100 MHz, Correction off; includes retrace time,
3700 points. Measurement speed can be improved by selecting the widest IF
bandwidth setting of 6000 Hz.
51 0.034
101 0.053
201 0.091
401 0.167
801 0.318
1601 0.621
