1.2 Upgrade Kit
One upgrade kit is required to install one I/O drawer. The I/O master drawer and
expansion drawer kits have identical contents.
Table 1–2 specifies the contents of the CK-BA70A-AA, the upgrade kit for either a
master or an expansion I/O drawer. The contents of the CK-BA70B-AA, the upgrade
kit for a master or expansion high-performance I/O drawer are also the same as listed
in Table 1–2.
Table 1–2 I/O Upgrade Kit Contents
Amt Part Number Description
2 12-46045-03 Slide
1 128557-001 Screw, self-tapping, 5.5mm x 12mm
2 17-00442-02 Power cords, 3m long
1 17-04991-04 Ground wire, 8AWG, #10
1 17-05097-04 Ethernet cable assembly
2 70-41067-01 Drawer latches
1 74-62379-01 Cable support rack
1 74-62381-01 Cable guide
2 74-62382-01 Shipping brackets
1 90-09984-18 Screw, M5 x 0.8 x 12mm long
4 90-09984-19 Screws, M4 x 0.7 x 8mm long (pan head)
12 90-09984-41 Screws, Phillips pan head, SEMS, M6 x 18mm
12 90-11476-01 Cagenuts
8 90-40347-02 Screws, machine, M4 x 6mm long (truss head)
2 70-41070-01 Cable guides
1 90-11593-02 Grommet strip
1 37-01729-02 Packaging material
1 70-41162-01 Cable support bracket
1 74-62871-01 Cable support base mounting bracket
1-4 hp AlphaServer ES47/ES80/GS1280 I/O Drawer Upgrade
