3.15 Set the Drawer ID
A newly installed I/O drawer needs to have a unique ID set on its OCP. Set
this ID number. Check your other drawer IDs, so that you do not create
duplicates.
Figure 3–19 Setting Drawer ID
Each component must have its ID set according to its position in the cabinet.
If, for example, you have no PCI in the position associated with ID-6, you do not assign that
ID to the drawer above it. The drawer above retains ID-7 to indicate its physical position in
the cabinet, and the drawer below is ID-5
3-30 hp AlphaServer ES47/ES80/GS1280 I/O Drawer Upgrade
