3. Remove the WLAN module (3) by pulling the module away from the slot at an angle.
NOTE: If the WLAN antenna is not connected to the terminal on the WLAN module, a protective sleeve must
be installed on the antenna connector, as shown in the following illustration.
Reverse this procedure to install the WLAN module.
Hall sensor board
Description
Spare part number
Hall sensor board 900815-001
28 Chapter 5 Removal and replacement procedures
