RTC battery
Description Spare part number
RTC battery 759981-001
Before removing the RTC battery, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 49), and then remove the following components:
●
Service cover (see
Service cover on page 55)
●
Keyboard (see
Keyboard on page 57)
●
Top cover (see
Top cover on page 60)
●
WLAN module (see
WLAN module on page 71)
●
USB board (see
USB board on page 67
●
Hard drive (see
Hard drive on page 68
●
System board (see
System board on page 83)
To remove the RTC battery:
1. Position the system board upside down.
94 Chapter 4 Removal and replacement procedures
