Service Reference Guide 483941-001 6–17
Removal and Replacement Procedures— Microtower (MT)/Small Form Factor (SFF) Chassis
6.8 Drives
The computer supports up to four drives that may be installed in various configurations.
This Section describes the procedure for replacing or upgrading the storage drives. A Torx T-15
screwdriver is needed to remove and install the guide screws on a drive.
Ä
CAUTION: Make sure personal files on the hard drive are backed up to an external storage device
before removing the hard drive. Failure to do so will result in data loss. After replacing the primary hard
drive, you will need to run the Restore Plus! CD to load the Compaq factory-installed files.
6.8.1 Locating Drive Positions
Drive Positions
*
*
* These apply for selected models and countries only.
To Next Page
