5–22 Maintenance and Service Guide
Removal and Replacement Procedures
5.10 Switch Cover
✎
Both switch cover spare part kits include the LED board and
LED board cable.
1. Prepare the notebook for disassembly (Section 5.3).
2. Remove the keyboard (Section 5.9).
3. Turn the notebook upside down with the rear panel
toward you.
4. Remove the three PM2.0×2.0 screws that secure the switch
cover to the notebook.
Removing the Switch Cover Screws
Switch Cover Spare Part Number Information
For use only with HP Compaq nw8240 and nc8230 models
For use only with HP Compaq nc8220 models
382680-001
384133-001
To Next Page
