Removal and Replacement Procedures
Maintenance and Service Guide 5–3
5.2 Disassembly Sequence Chart
Use the chart below to determine the section number to be
referenced when removing notebook components.
Disassembly Sequence Chart
Section Description
# of Screws Removed
5.3 Preparing the notebook for
disassembly
Battery pack
0
5.4 Hard drive 2 loosened to remove the
hard drive cover
1 loosened to remove the
hard drive
6 to disassemble hard drive
5.5 Notebook feet 0
5.6 MultiBay II device 1
5.7 External memory module 1 loosened to remove the
memory module
compartment cover
5.8 Bluetooth board 1 loosened to remove the
Bluetooth board cover
2 removed to remove
Bluetooth board
5.9 Keyboard 2
5.10 Switch cover 3 to remove the switch cover
6 to remove the LED board
5.11 RTC battery 0
5.12 Thermal plate 4 loosened
4 removed
To Next Page
