Removal and Replacement Procedures
Maintenance and Service Guide 5–7
5.4 Hard Drive
1. Prepare the notebook for disassembly (Section 5.3).
2. Loosen the 2 PM2.0×4.0 screws 1 that secure the hard drive
cover to the notebook.
3. Lift the left side of the hard drive cover and swing it to the
right 2.
4. Remove the hard drive cover.
✎
The hard drive cover is included in the Miscellaneous
Plastics Kit, spare part number 382691-001.
Removing the Hard Drive Cover
Hard Drive Spare Part Number Information
7200-rpm
60-GB 380950-001
5400-rpm
80-GB
60-GB
40-GB
379810-001
379809-001
379808-001
To Next Page
