Page #149 background imageLoading...
Page #149 background image
Cannot eject compact disc (tray-load unit).
Cause Solution
Disc not properly seated in the drive. Turn off the computer and insert a thin metal rod into the
emergency eject hole and push firmly. Slowly pull the tray
out from the drive until the tray is fully extended, then remove
the disc.
CD-ROM, CD-RW, DVD-ROM, or DVD-R/RW drive cannot read a disc or takes too long to start.
Cause Solution
Media is corrupt. Try different media to confirm whether media is valid.
Media has been inserted upside down. Re-insert the media with the label facing up.
The DVD-ROM drive takes longer to start because it has to
determine the type of media played, such as audio or video.
Wait at least 30 seconds to let the DVD-ROM drive
determine the type of media being played. If the disc still
does not start, read the other solutions listed for this topic.
CD or DVD disc is dirty. Clean CD or DVD with a CD cleaning kit, available from most
computer stores.
Windows does not detect the CD-ROM or DVD-ROM drive. 1. Use Device Manager to remove or uninstall the device.
To access Device Manager in Windows 7, click Start,
select Control Panel, and then select Device
Manager.
To access Device Manager in Windows 8, from the
Start screen, type c, select Control Panel from the list
of applications, and then select Device Manager.
2. Restart the computer and let Windows detect the CD or
DVD driver.
Recording or copying CDs is difficult or impossible.
Cause Solution
Wrong or poor quality media type. 1. Try using a slower speed when recording.
2. Verify that you are using the correct media for the drive.
3. Try a different brand of media. Quality varies widely
between manufacturers.
Solving USB Flash Drive Problems
If you encounter USB flash drive problems, common causes and solutions are listed in the following
table.
Solving USB Flash Drive Problems 141

Table of Contents

Other manuals for HP Compaq Pro 4300

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Compaq Pro 4300 and is the answer not in the manual?

HP Compaq Pro 4300 Specifications

General IconGeneral
Full HDNo
Panel typeTN
LED backlightYes
Display diagonal20 \
Display resolution1600 x 900 pixels
Native aspect ratio16:9
Tcase65.3 °C
Bus typeDMI
Processor cache3 MB
Processor cores2
Processor modeli3-3240
System bus rate5 GT/s
Processor familyIntel® Core™ i3
Processor seriesIntel Core i3-3200 Desktop Series
Processor socketLGA 1155 (Socket H2)
Processor threads4
Processor codenameIvy Bridge
Processor frequency3.4 GHz
Processor cache typeSmart Cache
Processor lithography22 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version2.0
Processor operating modes64-bit
PCI Express configurations1x16, 2x8
Thermal Design Power (TDP)55 W
CPU multiplier (bus/core ratio)34
Memory types supported by processorDDR3-SDRAM
Memory channels supported by processorDual
Memory clock speeds supported by processor1333, 1600 MHz
Memory bandwidth supported by processor (max)25.6 GB/s
Maximum internal memory supported by processor32 GB
Product typeAll-in-One PC
Motherboard chipsetIntel® H61
Internal memory4 GB
Memory slots typeSO-DIMM
Memory clock speed1600 MHz
Maximum internal memory16 GB
Memory layout (slots x size)1 x 4 GB
HDD speed7200 RPM
HDD interfaceSATA
Storage mediaHDD
Optical drive typeDVD Super Multi
Total storage capacity500 GB
Compatible memory cardsSD
Autonomy mode-
Storage drive interfaceSerial ATA
On-board graphics card ID0x152
Discrete graphics card modelNot available
On-board graphics card modelIntel® HD Graphics 2500
On-board graphics card familyIntel® HD Graphics
On-board graphics card base frequency650 MHz
On-board graphics card dynamic frequency (max)1050 MHz
Number of displays supported (on-board graphics)3
RMS rated power4 W
Wi-Fi standardsNot supported
Ethernet LAN data rates10, 100, 1000 Mbit/s
Headphone outputs1
USB 2.0 ports quantity6
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity0
Bundled softwareAdobe Flash Player\\r HP Marketplace\\r Bing\\r Microsoft Internet Explorer\\r PDF Complete Corporate Edition\\r WinZip Basic\\r Yahoo\\r Compre Office
Recovery operating systemWindows 8 Pro
Operating system installedWindows 7 Professional
Processor ARK ID65690
Processor package size37.5 x 37.5 mm
Supported instruction setsAVX, SSE4.1, SSE4.2
Thermal solution specificationPCG 2011C
Intel Secure Key Technology version0.00
Intel Identity Protection Technology version1.00
Product colorBlack
Country of originChina
Total megapixels1.3 MP
AC adapter power150 W
Operating temperature (T-T)5 - 35 °C
Operating relative humidity (H-H)15 - 80 %
Sustainability certificatesENERGY STAR
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)220 mm
Width (with stand)507 mm
Height (with stand)406 mm
Weight (with stand)5730 g
