Maintenance and S
ervi
ce Guide
A–3
Ta
b
l
e
A
-
4
External Monitor
Pin
Signal
Pin
Signal
1
Red analog
9
+5 VDC
2
Green analog
10
Ground
3
Blue analog
11
Monitor detect
4
Not connected
12
DDC 2B data
5
Ground
13
Hor
izontal sync
6
Ground analog
14
V
er
tical sync
7
Ground analog
15
DDC 2B cloc
k
8
Ground analog
195
197
