Hardware Setup
Connecting the Modem to an RJ-11 Jack
To connect the modem to an analog telephone line that
has an RJ-11 telephone jack:
✎
Telephone wall jacks and modem cables vary in appearance by
region and country.
1. Turn the tablet PC display-side up on a flat surface
near an RJ-11 telephone wall jack.
2. If your modem cable has noise suppression circuitry 1,
which prevents interference with TV and radio reception,
orient the circuitry end of the cable toward the tablet PC.
Å
To avoid the risk of electric shock, fire, or damage to the
equipment, do not plug a modem cable into a network jack.
3. Plug the modem cable into the RJ-11 (modem) jack 2 on the
tablet PC.
4. Plug the other end of the modem cable into the RJ-11
telephone wall jack 3.
Getting Started 1–5
