Product Description
Maintenance and Service Guide 1–13
Table 1-4
Rear Panel Components
Item Component Function
1 USB port Connects USB 1.1- and 2.0-compliant
devices to the tablet PC using a standard
USB cable.
2 RJ-11 (modem) jack Connects a modem cable. Enabled with
56K connectivity.
3 RJ-45 (network) jack Connects a network cable. Enabled with
10/100/1000BaseT connectivity.
4 Power connector Connects an AC adapter, an optional
AC adapter, or an optional power cable.
5 External monitor port Connects an optional VGA external monitor
or projector.
6 S-Video-out jack Is a 7-pin, dual-purpose jack.
It connects an optional S-Video device,
such as a television, VCR, camcorder,
overhead projector, or video capture card,
with an optional, standard (4-pin) S-Video
cable.
The extra 3 pins also enable an optional
S-Video-to-composite adapter to be used
with the tablet PC.
