6–4 Maintenance and Service Guide
Removal and Replacement Procedures
Section Description
# of Screws Removed
6.12 Heat sink 4
6.13 Processor 1 loosened
6.14 Internal memory module 0
6.15 Mini PCI communications card 0
Å
To prevent an unresponsive system and the display of a
warning message, install only a Mini PCI device authorized
for use in your tablet PC by the governmental agency that
regulates wireless devices in your country. If you install a
device and then receive a warning message, remove the
device to restore tablet PC functionality. Then contact
Customer Care.
6.16 Button board 1
6.17 Display assembly 6
6.18 Top cover 10
6.19 TouchPad 4
6.20 Speaker 2
6.21 Infrared board 1
6.22 System board 5
6.23 Modem board 2
6.24 RTC battery 0
Disassembly Sequence Chart
(Continued)
To Next Page
