Connecting the cables
NOTE: The monitor ships with select cables. Not all cables shown in this section are included with the
monitor.
1. Place the monitor in a convenient, well-ventilated location near the computer.
2. Before connecting the cables, route the cables through the cable routing hole in the center of the stand.
3. Connect a video cable.
NOTE: The monitor will automatically determine which inputs have valid video signals. The inputs can
be selected by pressing the Menu button to access the on-screen display (OSD) menu and selecting
Input Control.
ā
Connect one end of a VGA cable to the VGA connector on the rear of the monitor and the other end
to the VGA connector on the source device.
Setting up the monitor 7
