Blinking lights and boot error codes
The information below is from the white paper HP Business Notebook and Desktop PC F10 Setup, 2014
Business PC models.
In some cases, when the host processor is not executing code or does not have the necessary code to drive
the display, light blink codes inform you of a problem.
Table 8-7 Boot-error codes
Blink codes Error
Amber battery light: blinks 1 Hz continuously Embedded Controller unable to load rmware
Caps/num lock lights = 1 blink Processor not executing code
Caps/num lock lights = 2 blinks BIOS recovery code unable to nd valid BIOS recovery image
Caps/num lock lights = 3 blinks Memory module error
Caps/num lock lights = 4 blinks Graphics controller error
Caps/num lock lights = 5 blinks System board error
Caps/num lock lights = 6 blinks Intel Trusted Execution Technology (TXT) Error
Caps/num lock lights = 7 blinks Sure Start unable to nd valid BIOS Boot Block image
Caps/num lock lights = 8 blinks Sure Start has identied a problem (Manual Recovery Policy Set)
Processor not executing code
This computer has experienced a problem due to the failure of certain code to execute, resulting in a failed
startup of the processor. The issue could be related to the processor or the system board in the computer. If
the processor is socketed, be sure that the processor is seated correctly in the socket. If this error reoccurs,
refer to General troubleshooting steps on page 83.
NOTE: The computer will attempt to notify you of this problem through a series of blinking lights. When you
attempt to turn on the computer from an “O” or “Hibernated” state, lights associated with the caps lock and
num lock keys will both blink once followed by a pause, and then continue in a repeating pattern.
BIOS recovery code unable to nd valid BIOS recovery image
This computer has experienced a problem in locating a valid BIOS image, resulting in a failed startup. This
problem may be resolved by placing a clean copy of the system BIOS on a USB key or in the appropriate hard
drive directory and performing a reboot. If this error reoccurs, refer to General troubleshooting steps
on page 83.
NOTE: The computer will attempt to notify you of this problem through a series of blinking lights. When you
attempt to turn on the computer from an “O” or “Hibernated” state, lights associated with the caps lock and
num lock keys will both blink twice followed by a pause, and then continue in a repeating pattern.
Memory module error
This computer has experienced a memory initialization problem resulting in a failed startup. This issue may
be related to the memory modules in the computer. This problem may be resolved by ensuring that memory
modules are correctly inserted and seated. If this error reoccurs, a service event is required to determine the
source of the error (memory modules or system board) and take the appropriate corrective action.
Additional information 143

HP EliteBook 850 G4 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Silver
Country of origin	China
Bus type	OPI
Stepping	H0
Tjunction	100 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-7200U
System bus rate	4 GT/s
Processor family	Intel® Core™ i5
Processor socket	BGA 1356
Processor threads	4
Processor codename	Kaby Lake
Configurable TDP-up	25 W
Processor frequency	2.5 GHz
Processor cache type	Smart Cache
Configurable TDP-down	7.5 W
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	3.0
Processor boost frequency	3.1 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x2+2x1, 1x4, 2x2, 4x1
Thermal Design Power (TDP)	15 W
Configurable TDP-up frequency	2.7 GHz
Configurable TDP-down frequency	0.8 GHz
Maximum number of PCI Express lanes	12
Numeric keypad	Yes
Pointing device	Touchpad
Memory slots	2x SO-DIMM
Internal memory	8 GB
Memory clock speed	2133 MHz
Internal memory type	DDR4-SDRAM
Maximum internal memory	32 GB
Memory layout (slots x size)	1 x 8 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	PCI Express
Storage media	SSD
Total storage capacity	256 GB
Compatible memory cards	SD, SDHC, SDXC
Number of SSDs installed	1
Display diagonal	15.6 \
Native aspect ratio	16:9
On-board graphics card ID	0x5916
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 620
On-board graphics card family	Intel® HD Graphics
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	300 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1000 MHz
Battery capacity	51 Wh
Battery life (max)	14.7 h
Number of battery cells	3
AC adapter power	45 W
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	0
Sustainability certificates	ENERGY STAR
Processor code	SR2ZU
Processor ARK ID	95443
Processor package size	42 x 24 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Intel Identity Protection Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00
Intel segment tagging	Home Office, Small Business
HP segment	Business
HP Management tools	HP Driver Packs, HP SoftPaq Download Manager (SDM), HP System Software Manager (SSM), HP BIOS Config Utility (BCU), HP Client Catalog, HP Management Integration Kit, HP Device Access Manager, HP BIOSphere, HP Sure Start, HP Client Security
HP Software provided	HP ePrint Driver+JetAdvantage, HP Hotkey Support, HP Noise Cancellation, HP Workwise, HP Velocity
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	257.7 mm
Width	383.6 mm
Height	19.4 mm
Weight	1840 g
