Bottom cover
Description Spare part number
Bottom cover 843589-001
Bottom cover hinge caps (includes left and right caps) 809312-001
Rubber Kit (includes bottom cover screw covers) 809314-001
Keyboard/top cover with backlight (includes backlight cable and keyboard cable)
For use in Canada 835867-DB1
For use in the United States 835867-001
Keyboard/top cover (includes keyboard cable)
For use in Canada 835866-DB1
For use in the United States 835866-001
Before removing the bottom cover, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
4. Remove the battery (see Battery on page 24).
5. Remove the optical drive (see Optical drive on page 25).
Remove the bottom cover:
1. Position the computer upside down with the rear toward you.
2. Remove the four Phillips PM2.5×12.0 screws (1) that secure the hinge covers to the computer.
HP
Condential
28 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
