5. Lift the rear edge of the TouchPad and the rear bracket, and then remove them (3).
NOTE: When installing the TouchPad, note that the metal protrusion that extends from the TouchPad
is installed under the keyboard shield (4).
Reverse this procedure to install the TouchPad.
Display assembly
Before removing the display assembly, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
4. Remove the battery (see Battery on page 24).
5. Remove the optical drive (see Optical drive on page 25).
6. Remove the bottom cover (see Bottom cover on page 28).
Remove the display assembly:
1. Remove the four Phillips PM2.5×5.0 screws (1) that secure the display assembly to the computer.
2. Rotate the display hinges (2) back to the fully released position.
HP
Condential
Component replacement procedures 51
