Heat sink

NOTE: The heat sink spare part kit includes replacement thermal material.

Description Spare part number

For use only on computer models equipped with a graphics subsystem with dedicated video memory 806827-001

For use only on computer models equipped with a graphics subsystem with UMA memory and an Intel Core

i7-6700HQ processor

806826-001

For use only on computer models equipped with a graphics subsystem with UMA memory and an Intel Core

i7-6500U or Intel Core i5-6200U processor

828817-001

NOTE: To properly ventilate the computer, allow at least 7.6 cm (3.0 in) of clearance on the left side of

the computer. The computer uses an electric fan for ventilation. The fan is controlled by a temperature sensor

and is designed to turn on automatically when high temperature conditions exist. These conditions are

aected by high external temperatures, system power consumption, power management/battery

conservation congurations, battery fast charging, and software requirements. Exhaust air is displaced

through the ventilation grill located on the left side of the computer.

Before removing the heat sink, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn

the computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then

unplugging the AC adapter from the computer.

4. Remove the battery (see Battery on page 24).

5. Remove the optical drive (see Optical drive on page 25).

6. Remove the bottom cover (see Bottom cover on page 28).

7. Remove the fan (see Fan on page 37).

8. Remove the system board (see System board on page 40).

Remove the heat sink:

1. For computer models equipped with a graphics subsystem with discrete memory, in the order indicated,

remove the six Phillips PM2.0×3.0 screws (1) that secure the heat sink to the system board.

Condential

Component replacement procedures 43
