System board
NOTE: The system board spare part kit includes the processor and replacement thermal material.
Description Spare part number
For use only on computer models with model numbers 17-s100 through 17-s199:
Equipped with an Intel Core i7-7500U 2.70-GHz (SC turbo up to 3.50-GHz) processor (2133-MHz FSB, 4.0-
MB L3 cache, dual core, 15 W), an NVIDIA N16S-GT (GeForce 940M) graphics subsystem with 4-GB of
dedicated video memory, and the Window 10 operating system
904360-601
Equipped with an Intel Core i7-7500U 2.70-GHz (SC turbo up to 3.50-GHz) processor (2133-MHz FSB, 4.0-
MB L3 cache, dual core, 15 W), an NVIDIA N16S-GT (GeForce 940M) graphics subsystem with 4-GB of
dedicated video memory, and a non-Window 10 operating system
904360-001
Equipped with an Intel Core i7-7500U 2.70-GHz (SC turbo up to 3.50-GHz) processor (2133-MHz FSB, 4.0-
MB L3 cache, dual core, 15 W), an NVIDIA N16S-GT (GeForce 940M) graphics subsystem with 2-GB of
dedicated video memory, and the Window 10 operating system
904359-601
Equipped with an Intel Core i7-7500U 2.70-GHz (SC turbo up to 3.50-GHz) processor (2133-MHz FSB, 4.0-
MB L3 cache, dual core, 15 W), an NVIDIA N16S-GT (GeForce 940M) graphics subsystem with 2-GB of
dedicated video memory, and a non-Window 10 operating system
904359-001
For use on all computer models:
Equipped with an Intel Core i7-6500U 2.50-GHz (SC turbo up to 3.10-GHz) processor (1600-MHz FSB, 4.0-
MB L3 cache, dual core, 15 W), an NVIDIA N16S-GT (GeForce 940M) graphics subsystem with 4-GB of
dedicated video memory, and the Window 10 operating system
838262-601
Equipped with an Intel Core i7-6500U 2.50-GHz (SC turbo up to 3.10-GHz) processor (1600-MHz FSB, 4.0-
MB L3 cache, dual core, 15 W), an NVIDIA N16S-GT (GeForce 940M) graphics subsystem with 4-GB of
dedicated video memory, and a non-Window 10 operating system
838262-001
Equipped with an Intel Core i7-6500U 2.50-GHz (SC turbo up to 3.10-GHz) processor (1600-MHz FSB, 4.0-
MB L3 cache, dual core, 15 W), an NVIDIA N16S-GT (GeForce 940M) graphics subsystem with 2-GB of
dedicated video memory, and the Window 10 operating system
838261-601
Equipped with an Intel Core i7-6500U 2.50-GHz (SC turbo up to 3.10-GHz) processor (1600-MHz FSB, 4.0-
MB L3 cache, dual core, 15 W), an NVIDIA N16S-GT (GeForce 940M) graphics subsystem with 2-GB of
dedicated video memory, and a non-Window 10 operating system
838261-001
Equipped with an Intel Core i7-6700HQ 2.60-GHz (SC turbo up to 3.50-GHz) processor (1600-MHz FSB, 6.0-
MB L3 cache, dual core, 45 W (cTDP to 35 W)), a graphics subsystem with UMA memory, and the Window 10
operating system
835869-601
Equipped with an Intel Core i7-6700HQ 2.60-GHz (SC turbo up to 3.50-GHz) processor (1600-MHz FSB, 6.0-
MB L3 cache, dual core, 45 W (cTDP to 35 W)), a graphics subsystem with UMA memory, and a non-Window
10 operating system
835869-001
Equipped with an Intel Core i7-6500U 2.50-GHz (SC turbo up to 3.10-GHz) processor (1600-MHz FSB, 4.0-
MB L3 cache, dual core, 15 W), a graphics subsystem with UMA memory, and the Window 10
operating system
841040-601
Equipped with an Intel Core i7-6500U 2.50-GHz (SC turbo up to 3.10-GHz) processor (1600-MHz FSB, 4.0-
MB L3 cache, dual core, 15 W), a graphics subsystem with UMA memory, and a non-Window 10
operating system
841040-001
Equipped with an Intel Core i5-6200U 2.30-GHz (SC turbo up to 2.80-GHz) processor (1600-MHz FSB, 3.0-
MB L3 cache, quad core, 15 W), a graphics subsystem with UMA memory, and the Window 10
operating system
838260-601
Equipped with an Intel Core i5-6200U 2.30-GHz (SC turbo up to 2.80-GHz) processor (1600-MHz FSB, 3.0-
MB L3 cache, quad core, 15 W), a graphics subsystem with UMA memory, and a non-Window 10
operating system
838260-001
HP Condential
40 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
