Hard drive
NOTE: The hard drive spare part kit does not include the hard drive brackets or the hard drive cable.
The hard drive brackets and the hard drive cable are included in the Hard Drive Hardware Kit, spare part
number 809296-001.
Description Spare part number
For use only on computer models with model numbers 17-s100 through 17-s199:
1-TB, 7200-rpm, SATA, 9.5-mm 766644-005
For use on all computer models:
2-TB, 5400-rpm, SATA, 9.5-mm 801808-005
1-TB, 5400-rpm, SATA, 9.5-mm 778192-005
1-TB, 5400-rpm, 8-GB hybrid, 7.0-mm 731999-005
Before removing the hard drive, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
4. Remove the battery (see Battery on page 24).
5. Remove the optical drive (see Optical drive on page 25).
6. Remove the bottom cover (see Bottom cover on page 28).
Remove the hard drive:
1. Release the zero insertion force (ZIF) connector (1) to which the hard drive cable is connected, and then
disconnect the hard drive cable from the system board.
HP
Condential
Component replacement procedures 31
