Miscellaneous parts
Component Spare part number
HP Smart AC adapter, 45-W, non-PFC, 4.5-mm, non-slim 741727-001
Power cord (3-pin, black, 1.0-m):
For use in Europe 755530-021
For use in Israel 755530-BB1
For use in Denmark 755530-081
For use in North America 755530-001
For use in Switzerland 755530-111
For use in the United Kingdom and Singapore 755530-031
Rubber Feet Kit 768019-001
Screw Kit 774604-001
HDMI to VGA adapter 701943-001
Pen 773175-001
Sequential part number listing
Spare part number Description
691739-005 2-GB memory module (PC3L, 12800, 1600-MHz)
691740-005 4-GB memory module (PC3L, 12800, 1600-MHz)
693374-005 8-GB memory module (PC3L, 12800, 1600-MHz)
701943-001 HDMI to VGA adapter
710662-005 Intel Dual Band Wireless-AC 3160 802.11 ac 1x1 WiFi + BT 4.0 combo adapter
732000-005 500-GB hard drive, 5400-rpm, 8 GB hybrid SSD, 7.0-mm
NOTE: The hard drive bracket and hard drive connector cable are included in the Hard Drive Hardware
Kit, spare part number 768020-001.
733476-005 Qualcomm QCA9565 802.11bgn 1x1 Wi-Fi + BT4.0 Combo Adapter
741727-001 45-W HP Smart AC adapter (non-PFC, 4.5-mm, non-slim)
747080-001 External DVD±RW Double-Layer with SuperMulti Drive
748599-001 HP hs3110 HSPA+ Mobile Broadband Module
752099-005 750-GB hard drive, 5400-rpm, 7.0-mm
NOTE: The hard drive bracket and hard drive connector cable are included in the Hard Drive Hardware
Kit, spare part number 768020-001.
755530-001 Power cord for use in North America (3-pin, black, 1.0-m)
755530-021 Power cord for use in Europe (3-pin, black, 1.0-m)
Miscellaneous parts 19

HP ENVY x360 Convertible PC Specifications

General

Category	Laptop
Type	Convertible
Operating System	Windows 10, Windows 11
Touchscreen	Yes
Audio	Bang & Olufsen, Dual Speakers
Display Size	13.3 inches
Display Resolution	1920 x 1080, 3840 x 2160
Processor	Intel Core i5, Intel Core i7, AMD Ryzen 5, AMD Ryzen 7
RAM	8 GB, 16 GB
Storage	256GB SSD, 512GB SSD, 1TB SSD
Graphics	AMD Radeon Graphics, Intel Iris Xe Graphics
Wireless	Wi-Fi 6
Bluetooth	Bluetooth 5.0
Ports	USB-C, USB-A, HDMI, Headphone/Microphone combo jack

Summary

Product Description

External Component Identification

Right Side Components

Identifies ports and indicators on the right side of the PC.

Left Side Components

Identifies ports and indicators on the left side of the PC.

Display Features

Describes the screen components, features, and viewing angles.

Display Modes

Explains different ways to orient the display for various uses.

Top Panel Components

Details components on the top surface, including the touchpad and buttons.

Bottom Panel Components

Describes components located on the bottom of the PC, such as vents.

Service and PCID Labels

Explains the purpose and location of essential identification labels.

Illustrated Parts Catalog

Computer Major Components

Lists and illustrates main internal hardware parts with spare numbers.

Display Assembly Subcomponents

Shows and lists spare parts for the display assembly.

Mass Storage Devices

Identifies available hard drive and SSD options and their spare parts.

Miscellaneous Parts

Lists various small, general-purpose replacement parts.

Removal and Replacement Preliminary Requirements

Tools Required for Service

Lists the necessary tools for performing component removal and replacement.

Service Considerations

Provides essential guidelines and cautions for servicing the computer.

Drive Handling Precautions

Details precautions for safely handling storage drives to prevent damage.

Grounding Guidelines

Procedures to prevent electrostatic discharge (ESD) damage to components.

Removal and Replacement Procedures for Authorized Service Providers

Component Replacement Procedures Overview

General information on replacing computer components.

Top Cover Replacement

Step-by-step instructions for removing and replacing the top cover.

Battery Replacement

Procedure for safely removing and installing the battery.

Hard Drive Replacement

Instructions for removing and installing the primary hard drive.

Solid-State Drive (SSD) Replacement

Procedure for removing and installing the SSD.

System Board Replacement

Detailed steps for removing and installing the motherboard.

Memory Module Replacement

Instructions for adding or replacing RAM modules.

Display Assembly Replacement

Procedure for removing and installing the complete display assembly.

Using Setup Utility (BIOS) and HP PC Hardware Diagnostics (UEFI)

Starting Setup Utility (BIOS)

How to access and enter the BIOS setup utility.

Updating the BIOS

Information and steps for updating the system's BIOS firmware.

Using HP PC Hardware Diagnostics (UEFI)

Instructions for running diagnostic tests on computer hardware.

Specifications

Computer Specifications

Details on system dimensions, weight, input power, and environmental conditions.

Hard Drive Specifications

Technical details for the computer's hard drive options.

Solid-State Drive Specifications

Technical details for the computer's solid-state drive options.

Backing Up, Restoring, and Recovering

Creating Recovery Media and Backups

Guidance on creating system backups and recovery media.

Restore and Recovery Options

Overview of different system restoration and recovery methods.

Recovering Using HP Recovery Manager

Detailed procedures for using HP Recovery Manager for system restoration.

Power Cord Set Requirements

Requirements for All Countries

General specifications applicable to power cords worldwide.

Requirements for Specific Countries and Regions

Region-specific power cord standards and agency certifications.

Recycling
