HP ENVY x360 Convertible User Manual

Hard drive
NOTE: The Hard Drive Hardware Kit, spare part number 808238-001, includes the hard drive bracket and
hard drive connector cable.
Description Spare part number
1-TB, 5400-rpm, 7 mm 762990-005
750 GB, 5400 rpm hard drive, 7 mm 752099-005
500-GB, 5400-rpm, 7 mm, hybrid 8 GB SSD 732000-005
500-GB, 5400-rpm, 7 mm 778186-005
Hard Drive Hardware Kit (includes hard drive bracket and connector cable) 808238-001
Before removing the hard drive, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the top cover (see Top cover on page 27).
5. Disconnect the battery.
Remove the hard drive:
1. Disconnect the hard drive connector cable (1) from the system board.
30 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts

HP ENVY x360 Convertible Specifications

General

Series	ENVY x360
Convertible	Yes
Touchscreen	Yes
Display Size	13.3 inch / 15.6 inch
RAM	8GB or 16GB
Storage	512 GB SSD / 1 TB SSD
Graphics	AMD Radeon Graphics or Intel Iris Xe Graphics
Battery	3-cell Li-ion
Weight	1.32 kg
Ports	1x headphone/microphone combo
Wireless	Wi-Fi 6
Audio	Audio by Bang & Olufsen; Dual speakers
Processor Type	Intel Core i7 / AMD Ryzen 7
