USB board (USB/volume/hard drive LED/card reader)

Description Spare part number

USB board (includes cable) 807527-001

Before removing the USB board, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then

unplugging the AC adapter from the computer.

4. Remove the top cover (see Top cover on page 27).

5. Disconnect the battery.

To remove the USB board:

1. Disconnect the cable from the system board (1).

2. Remove the two Phillips PM2.0×3.0 screws (2) that secure the board to the computer.

Component replacement procedures 37

Questions and Answers:

Need help?

Do you have a question about the HP ENVY x360 Convertible and is the answer not in the manual?

HP ENVY x360 Convertible Specifications

General

Series	ENVY x360
Convertible	Yes
Touchscreen	Yes
Display Size	13.3 inch / 15.6 inch
RAM	8GB or 16GB
Storage	512 GB SSD / 1 TB SSD
Graphics	AMD Radeon Graphics or Intel Iris Xe Graphics
Battery	3-cell Li-ion
Weight	1.32 kg
Ports	1x headphone/microphone combo
Wireless	Wi-Fi 6
Audio	Audio by Bang & Olufsen; Dual speakers
Processor Type	Intel Core i7 / AMD Ryzen 7
