Power connector cable

Description Spare part number

Power connector cable 807522-001

Before removing the power connector cable, follow these steps:

1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect the power from the computer by unplugging the power cord from the computer.

3. Disconnect all external devices from the computer.

4. Remove the top cover (see Top cover on page 27).

5. Remove the system board (see System board on page 39).

6. Remove the display (see Display assembly subcomponents on page 19).

Remove the power connector cable:

1. Remove the Phillips PM2.0×2.0 screw (1) that secures the bracket to the computer.

2. Remove the bracket from the computer (2).

3. Pull the connector out from under the rear corner of the computer (3).

4. Remove the power connector cable.

Reverse this procedure to install the power connector cable.

58 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts
