HP ENVY x360 Convertible User Manual

Memory module
Description Spare part number
8-GB (DDR3L-1600) 693374-005
4-GB (DDR3L-1600) 691740-005
Before removing a memory module, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the top cover (see Top cover on page 27).
5. Remove the system board (see System board on page 39).
To remove a memory module:
1. Position the system board upside-down.
2. Press in on either side of the memory cover close to the edge of the system board (1).
3. Lift the cover o the system board (2).
4. Spread the retaining tabs (1) on each side of the memory module slot to release the memory module.
(The memory module tilts up.)
42 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts

HP ENVY x360 Convertible Specifications

General

Series	ENVY x360
Convertible	Yes
Touchscreen	Yes
Display Size	13.3 inch / 15.6 inch
RAM	8GB or 16GB
Storage	512 GB SSD / 1 TB SSD
Graphics	AMD Radeon Graphics or Intel Iris Xe Graphics
Battery	3-cell Li-ion
Weight	1.32 kg
Ports	1x headphone/microphone combo
Wireless	Wi-Fi 6
Audio	Audio by Bang & Olufsen; Dual speakers
Processor Type	Intel Core i7 / AMD Ryzen 7
