3–4 User Guide
Setting Up the Monitor
Selecting the Signal Connectors and
Cables
The monitor features two DVI-I connectors capable of supporting
either analog or digital input.
The video mode supported by the DVI-I connector is determined
by the video cable used.
■ For digital operation, use the DVI-D signal cable provided.
Connect the DVI-D signal cable to a DVI-I connector on the
monitor and the other end to the DVI connector on the
computer.
■ For analog operation, use the DVI-I to VGA signal cable
provided (pre-attached to monitor). Connect the DVI-I to
VGA signal cable to the video connector on the computer.
The monitor will automatically determine which inputs have
valid video signals. The inputs can be selected through the
On-Screen Display (OSD) feature by pressing the Input Select
button on the front panel.
✎
To use the DVI-D signal cable, you must first remove the DVI-I
to VGA signal cable that is pre-attached to the monitor.
6 USB Downstream
Connectors
Connects optional USB devices to the monitor.
7 USB Downstream
Connectors (side
panel)
Connects optional USB devices to the monitor.
Component Function
