3–14 User Guide
Setting Up the Monitor
Mounting the Monitor
1. Remove the monitor pedestal base. Refer to “Removing the
Monitor Pedestal” steps in the previous section.
Ä
CAUTION: This monitor supports the VESA industry standard
100mm mounting holes. To attach a third party mounting solution to
the monitor, four 4mm, 0.7 pitch, and 10mm long screws are
required (not provided with the monitor). Longer screws should not be
used because they may damage the monitor. It is important to verify
that the manufacturer’s mounting solution is compliant with the VESA
standard and is rated to support the weight of the monitor display
panel. For best performance, it is important to use the power and
video cable provided with the monitor.
2. Remove the quick release plate from the pedestal base by
removing the four screws.
Removing the Quick Release Plate from the Pedestal Base
