HP JG221A Installation Guide

13
Switch model
Installation methods
Installation accessories
 Mounting the switch on a
workbench
Rubber pad: See Figure 19 (supplied
with the switch).
A3100-16 v2 SI
A3100-16 v2 EI
 Installing the switch into the
19-inch rack (Rack mounting by
using front mounting brackets)
Front mounting bracket: HP A3100-16
Rack Mount Kit (JD321A).
See callout C in Figure 17 (optional).
 Mounting the switch on a
workbench
Rubber pad: See Figure 19 (supplied
with the switch).
A3100-8 v2 SI
A3100-8 v2 EI
 Installing the switch into the
19-inch rack (Rack mounting by
using front mounting brackets)
Front mounting bracket: HP A3100-8
Rack Mount Kit (JD322A).
See callout B in Figure 17 (optional).
 Mounting the switch on a
workbench
Rubber pad: See Figure 19 (supplied
with the switch).
A3100-24-PoE v2 EI
 Installing the switch into the
19-inch rack (Rack mounting by
using front and rear mounting
brackets)
Front mounting bracket. See callout A in
Figure 17 (supplied with the switch).
Rear mounting bracket: See Figure 18
(supplied with the switch).
 Mounting the switch on a
workbench
Rubber pad: See Figure 19 (supplied
with the switch).
A3100-16-PoE v2 EI
A3100-8-PoE v2 EI
 Installing the switch into the
19-inch rack (Rack mounting by
using front mounting brackets)
Front mounting bracket: HP
A3100-16-PoE and 8-PoE Rack Mount
Kit (JD323A).
See callout D in Figure 17 (optional).
 Mounting the switch on a
workbench
Rubber pad: See Figure 19 (supplied
with the switch).
Installation accessories
Mounting brackets for rack mounting
The A3100 v2 Switch Series provides different mounting brackets for different models. Select them as
required.
