HP JG221A Installation Guide

2
Rear panel
Figure 2 A3100-24 v2 SI/A3100-24 v2 EI rear panel
1
2
(1) Grounding screw
(2) AC-input power receptacle
A3100-16 v2 SI/A3100-16 v2 EI
Front panel
Figure 3 A3100-16 v2 SI/A3100-16 v2 EI front panel
1
2
3
4
5
678
(1) Speed LED for a 10/100Base-TX Ethernet port
(2) 10/100Base-TX Ethernet ports
(3) Speed LED for a combo interface
(4) Console port
(5) Combo interface (10/100/1000Base-T Ethernet port on the left, 100/1000Base-X SFP port on the right)
(6) Link/Act LED for a combo interface
(7) Link/Act LED for a 10/100Base-TX Ethernet port
(8) Power LED
Rear panel
Figure 4 A3100-16 v2 SI/A3100-16 v2 EI rear panel
1
2
(1) Grounding screw
(2) AC-input power receptacle

HP JG221A Specifications

General

Brand	HP
Model	JG221A
Category	Switch
Language	English
