Appendix B Ports and LEDs
Ports
Console port
All A3100 v2 switches have one console port on the front panel.
Table 14 Console port specifications
Item
Specification
Connector type
RJ-45
Compliant standard
Asynchronous EIA/TIA-232
Transmission baud rate
9600 bps (default) to 115200 bps
Services
 Provides connection to an ASCII terminal.
 Provides connection to the serial port of a local or remote (through a pair of
modems) PC running terminal emulation program.
10/100Base-TX Ethernet port
All A3100 v2 switches provide 10/100Base-TX auto-sensing Ethernet ports on their front panels.
Table 15 10/100Base-TX Ethernet port specifications
Item
Specification
Connector type
RJ-45
Interface attributes
 10 Mbps, full/half duplex
 100 Mbps, full/half duplex
 MDI/MDI-X, auto-sensing
Max transmission
distance
100 m (328.08 ft)
Transmission medium
Category-5 twisted pair cable
Standards
IEEE 802.3i, 802.3u
Combo interface
All A3100 v2 switches offer combo interfaces. Each combo interface has one 100/1000Base-X fiber SFP
port and one 10/100/1000Base-T auto-sensing copper Ethernet port. These two ports share one port name
and port view and cannot work simultaneously. When you activate one port (by using the combo enable
{ copper | fiber } command, the other port automatically shuts down. For the number of combo interfaces
available on each A3100 v2 switch, see Table 10, Table 11, and Table 12.
