HP L1740 User Manual

4–4 User Guide
Operating the Monitor
Front Panel Controls
Front Panel Controls
No. Control Function
1 Auto Adjust Activates the auto adjustment feature for optimum
image.
2 Menu Opens the On-Screen Display (OSD) menu.
3
– (Minus) • If OSD is on, press to navigate backward through
the OSD menu features and decrease adjustment
levels.
• If OSD is off, press to enable the DVI signal input
(available on select models)
4
+ (Plus) • If OSD is on, press to navigate forward through the
OSD menu features and increase adjustment levels.
• If OSD is off, press to enable the VGA signal input.
5 Power Turns the monitor on or off.

HP L1740 Specifications

General

3D	No
Response time	8 ms
Display diagonal	17 \
Display resolution	1280 x 1024 pixels
Viewing angle, vertical	135 °
Contrast ratio (dynamic)	-
Contrast ratio (typical)	500:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	150 °
Digital vertical frequency	56 - 76 Hz
Digital horizontal frequency	30 - 83 kHz
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	720 x 400, 832 x 624, 1152 x 870, 1024 x 768 (XGA), 1360 x 768 (WXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
USB hub version	2.0
DVI-I ports quantity	0
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
Power consumption (max)	60 W
Power consumption (average)	33 W
Power consumption (standby)	2 W
Power consumption (typical)	40 W
Product color	Black, White
Country of origin	China
Package weight	8800 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	248 mm
Height (with stand)	490 mm
Weight (with stand)	7000 g
Depth (without stand)	62 mm
Width (without stand)	371 mm
Height (without stand)	315 mm
Weight (without stand)	3760 g
