HP L1740 User Manual

User Guide B–1
B
Technical Specifications
✎
All performance specifications are provided by the component
manufacturers. Performance specifications represent the highest
specification of all HP’s component manufacturers’ typical level
specifications for performance and actual performance may vary
either higher or lower.
L1740 Flat Panel Monitor
L1740 Flat Panel Monitor
Display
Type
17.0 inches
TFT LCD
43.2 cm
Viewable Image Size 17.0-inch diagonal 43.2 cm
Tilt
Swivel
--5 to 35°
--90 to 90°
Face Treatment Anti-glare polarizer with
hard coating
Maximum Weight
(Unpacked, base attached)
17.6 lbs. 8.0 kg
Dimensions
Height (maximum)
Depth
Width
18.8 inches
10.4 inches
14.6 inches
479.5 mm
265.0 mm
373.3 mm

HP L1740 Specifications

General

3D	No
Response time	8 ms
Display diagonal	17 \
Display resolution	1280 x 1024 pixels
Viewing angle, vertical	135 °
Contrast ratio (dynamic)	-
Contrast ratio (typical)	500:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	150 °
Digital vertical frequency	56 - 76 Hz
Digital horizontal frequency	30 - 83 kHz
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	720 x 400, 832 x 624, 1152 x 870, 1024 x 768 (XGA), 1360 x 768 (WXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
USB hub version	2.0
DVI-I ports quantity	0
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
Power consumption (max)	60 W
Power consumption (average)	33 W
Power consumption (standby)	2 W
Power consumption (typical)	40 W
Product color	Black, White
Country of origin	China
Package weight	8800 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	248 mm
Height (with stand)	490 mm
Weight (with stand)	7000 g
Depth (without stand)	62 mm
Width (without stand)	371 mm
Height (without stand)	315 mm
Weight (without stand)	3760 g
